| Carbon Steel H-Beam Specifications |
| Property / Specification | Description / Common Values |
| Common Grades | A36, A572 Gr.50, SS400, Q235B, Q345B, S235JR, S355JR |
| Standard | ASTM A6/A36, ASTM A572, JIS G3192, GB/T 11263, EN 10025 |
| Type | Wide Flange (W), Standard (S), Bearing Pile (HP) |
| Common Sizes (mm/in) | 100x100mm - 900x300mm (4"x4" - 36"x12") |
| Flange Width (mm/in) | 50mm - 300mm (2" - 12") |
| Web Height (mm/in) | 100mm - 900mm (4" - 36") |
| Flange Thickness (mm/in) | 5mm - 40mm (0.2" - 1.6") |
| Web Thickness (mm/in) | 5mm - 35mm (0.2" - 1.4") |
| Length | 6m (20'), 12m (40'), Custom Lengths |
| Surface Finish | Hot Rolled (HR), Shot Blasted, Primed |
| Tolerance | ASTM A6/A6M, JIS G3192 Standard Tolerances |
| Optional / Additional Information Table |
| Feature | Details |
| Core Characteristics | High Strength-to-Weight Ratio, Excellent Load-Bearing Capacity, Weldability, Machinability |
| Common Applications | Structural Framing, Building Columns, Bridge Construction, Heavy Equipment Supports, Industrial Racks |
| Packaging | Steel Strapping, Protective End Caps, Wooden Spacers, Weatherproof Wrapping |
| Certification | Mill Test Certificate (MTC) per EN 10204 3.1 |
| Testing | Tensile Test, Charpy Impact Test, Ultrasonic Testing, Dimensional Inspection |
| Marking | Grade, Size, Heat Number, Manufacturer, Standard Compliance |
